BriskHeat® BIH321020 XtremeFLEX® BIH Heavy Insulated Heat Tape, W x L: 3.25 x 24-Inch, 120V, Opposite End Leads
- Width: 3.25-inches (83mm); length: 24-inches (610mm); total watts: 418; voltage: 120V
- Heavy insulated heat tape is constructed of a knitted and double-braided fiberglass outer sheath cover that is suitable for electrically conductive surfaces
- Max exposure temperature: 900°F (482°C); power density: 5.1 watts/square inch (0.008 watts/square mm)
- Power leads on opposite ends; includes high-temperature tie-downs for easy installation
- Perfect for heating laboratory apparatus, gas tubing, temporary heat, valves and more; requires temperature controller (sold separately)
- Sold individually
- Manufacturer: BriskHeat
- Manufacturer Part No: BRH-BIH321020
Details
The BriskHeat® XtremeFLEX® BIH Series heavy insulated heat tape is constructed of a knitted and double-braided fiberglass outer sheath cover. It has a single power lead on opposite ends and includes high-temperature tie-downs for easy installation. This tape provides exceptional flexibility and durability with rapid thermal response and is suitable for electrically conductive surfaces. A temperature controller is required (sold separately). Perfect for a wide range of applications including heating laboratory apparatus, gas tubing, temporary heat, valves and more. BIH Series heavy insulated heat tape can tolerate a maximum exposure temperature of 900°F (482°C). The power density is 8.6watts/sq in (0.013watts/sq mm). Includes 24in (610mm) power leads with separable standard 2-prong power plug (NEMA 1-15). Requires Temperature Controller (Sold Separately). Material: Fiberglass, Knitted And Double-Braided. Maximum Exposure Temperature: 900°F (482°C). Power Density: 8.6w/sq in (0.013w/sq mm). Width: 3.25in (83mm). Length: 24in (610mm). Total Watts: 418. Voltage: 120V. BriskHeat® #: BIH321020.
Documents & Videos
The BriskHeat® XtremeFLEX® BIH Series heavy insulated heat tape is constructed of a knitted and double-braided fiberglass outer sheath cover. It has a single power lead on opposite ends and includes high-temperature tie-downs for easy installation. This tape provides exceptional flexibility and durability with rapid thermal response and is suitable for electrically conductive surfaces. A temperature controller is required (sold separately). Perfect for a wide range of applications including heating laboratory apparatus, gas tubing, temporary heat, valves and more. BIH Series heavy insulated heat tape can tolerate a maximum exposure temperature of 900°F (482°C). The power density is 8.6watts/sq in (0.013watts/sq mm). Includes 24in (610mm) power leads with separable standard 2-prong power plug (NEMA 1-15). Requires Temperature Controller (Sold Separately). Material: Fiberglass, Knitted And Double-Braided. Maximum Exposure Temperature: 900°F (482°C). Power Density: 8.6w/sq in (0.013w/sq mm). Width: 3.25in (83mm). Length: 24in (610mm). Total Watts: 418. Voltage: 120V. BriskHeat® #: BIH321020.
