KemLab™ HARE-SQ™ 2-100ML Negative High Aspect Ratio Epoxy Photoresist, 2um Film Thickness, 100mL Bottle (SAMPLE)
Notice: Hazardous chemicals and products will incur additional Hazmat Fees and/or mandatory shipment via LTL Motor Freight
- KemLab™ HARE-SQ™ negative tone photoresist uses an epoxy resin with superior cleanliness and excellent reproducibility
- Film Thickness: 2 microns. Consistent surface energy of crosslinked resist, (an important property for microfluidic applications.
- Fully compatible with SU-8 processes. KemLab™ HARE-SQ™ negative tone epoxy photoresist is designed for use with KemLab™ SQ developer.
- Softbake for the KemLab™ HARE-SQ™ negative tone photoresist utilizes a two-step bake on a contact hot plate in order to minimize film stress and adhesion issues.
- Competes with SU8 2 Negative Tone Photoresist
- 100mL SAMPLE Bottle
- Manufacturer Part No: HARESQ2-100ML
PLEASE NOTE: Product images and descriptions may not exactly represent the product. Prior to making your purchase, please confirm that the manufacturer part number shown above matches the product you seek. Returns are not allowed for such differences if the correct manufacturer part number is shipped.
Details
KemLab™ HARE-SQ™ is an epoxy based negative photoresist designed for polymeric MEMS, microfluidics, micromachining and other microelectronic applications. The HARE-SQ system is designed for use in thick film applications of 2 to 100 microns, and is ideal for use in permanent applications in which the photoresist remains within the finished device.
Documents & Videos
KemLab™ HARE-SQ™ is an epoxy based negative photoresist designed for polymeric MEMS, microfluidics, micromachining and other microelectronic applications. The HARE-SQ system is designed for use in thick film applications of 2 to 100 microns, and is ideal for use in permanent applications in which the photoresist remains within the finished device.
