Thermo Scientific™ 1550028 Advanced AC150 Immersion Circulator for Bath with Bridge, Range: Ambient +13 to 150°C, 115V/60Hz
Details
- Temperature stability: 0.01°C, 5 Programmable Temperature Setting
- Controller: AC150, Flow Rate: 20Liter/min., Maximum Pressure: 475mbar/6.89psi, Heating Capacity (Metric): 1.2kW
- Acoustic and visual alarm, Auto-Restart feature after power failure
- Fluid selection with predefined temperature limits, Safety Class: 3/FL
- Dimensions(L x W x H): 7.8 x 6.4 x 14.6-Inch.
- Sold individually
Thermo Scientific™ AC150 is ideal when applications require greater pumping performance, ramp programming, application alarms and temperature ranges from −50° to +150°C. Features include an enhanced digital display and easy–to–use touchpad settings, allowing you to easily tune the temperature to meet your specific application requirements.
- Max. temperature: 150°C
- Low-liquid level alarm for Safety Class III
- Automatic controller shutdown at detection of excessive high temperature, low liquid level or motor overload
- USB communication port and options for RS-232, RS-485, Ethernet/LAN, Analog I/O
- Programmable application temperature alarm with user selected alarm, go-safe-state or shut off option
- Self-Tuning PID controller for optimized temperature control
- Five programmable set point temperatures
- RTA (Real Temperature Adjustment) for calibration
- Internal or external temperature control mode (Remote Sensor, NAMUR type)
- Pump speed adjustment to three levels for turbulance control
- Powerful force and suction pump for external open and closed applications
- Three languages (English, German, French)
- Change digital display resolution between 0.1 and 0.01 and between °C — °F — °K
- Acoustic and optical alarm
- Auto-Restart feature after power failure
Includes:8mm and 12mm hose barbs with bridge (–0026, –0029, –0021 only), pump plug for external circulation, 6ft. power cord.
- Warranty varies by country, please contact us for details
